Wooden Spoon Carved Cutting Machine (CCM-003S)
This is the latest machine for wooden Spoon carved cutting (punching) and shape forming. It adopts super feeding system, no need gear changing, less noise and with high stability and durability.The service life is 8 times more than previous model.
|
Model |
CCM-003S |
|
Name |
Carved Cutting Machine (also called ice cream stick punching machine) |
|
Function |
Carved Cutting Wooden Veneer into wooden TONGUE DEPRESSOR STICK FOR MEDICAL USE.For example, making 150mm*18mm*1.8mm tongue depressor sticks.Before using this machine, you need to have wooden veneer which is ready., with thickness about 1.8mm |
|
Power |
2.2 KW |
|
Working Voltage |
380V, 50HZ (Three phase) Can be made according to your local working voltage |
|
Machine Weight |
550 KGS |
|
Gross Weight |
620 KGS |
|
Machine Size |
1200*800*1200 MM |
|
Output |
It can process about 1 to 1.25 cubic meter wood per hour. |
|
Application |
Shape forming of Wooden Spoon and other products,Ice Cream Stick Production Line, Wooden Tongue depressor stick Production Line, Wooden spoon Production Line,Ice cream stick making machine,Wooden tongue depressor stick machine, Wooden ice spoon making machine |
Our company has made great improvements on our carved cutting machine.CCM-003S carved cutting machine is our latest model for shape forming ice cream stick ,and other shape or sizes of products.This machine:Super feeding system、No need to change gear when product size is changed、Easy adjustment、Less noise、High quality parts、Automatic lubricating system
