MG256A-500 Peeling Machine

MG256A-500 Peeling Machine

MG256A-500 Peeling Machine
CategoriesOther Wooden Machine
AlbumView larger image
Update Time2020-08-08
Detail Information


Product Description

Product Features

1.PLC programming, inverter control, digital display control interface.

2.It is run by conveyor belt and ball screw, which runs smoothly and has high processing precision.

3.Hydraulic tensioning system ensures that the saw blade is in optimal tension and extends the life of the saw blade.

4.Achieve automatic cooling, lubrication, dust removal system, one step in place, safe and environmentally friendly.

5.Fast sawing speed, automatic, safe and reliable sawing process, high safety performance.

6.Reasonable structure, small footprint, easy installation, commissioning and movement


Technical Parameters:



Cutting the maximum width of the skin

500 MM

Cutting the maximum height of the skin

230 MM

Saw wheel diameter

Φ654 MM

Saw wheel width

95 MM

Main motor power

18.5 KW

Total power

21 KW

Feed rate

0-20 M/MIN

Saw blade size

5080×80×0.9 MM

Machine tool size

2800×2300×2100 MM


1800 KGS


4000 KGS
